Technical parameters
Rim Diameter：14″-46″
Max.Tire Weight:1300kg
Max.Wheel Diameter:1800mm
Max.Wheel Width:800mm
Working Pressure:150-180bar
Working Voltage:380/220V
Hydraulic motor displacement:3.0ml/r
Hydraulic Motor:3.0KW
Tire side pressure:2500kg
Machine Weight:604kg
Application
This product is suitable for assembling and disassembling tires with center hole diameter between 14 "and 46" .
Product Features
It can assemble and disassemble all kinds of tires for truck, bus and engineering vehicle.
Product Performance
1. This is the automatic tyre changer. Remove the tire without crowbar, do not hurt the wheel hub and do not hurt the tire.
2. The mobile low-voltage control handle is used for operation. The control console is light and convenient to move.
3. Operating voltage is 24 V, safe and stable.
4. Automatic lifting, stretching and clamping of supporting arm. Tire removal device hook automatic head lifting. The pulley moves automatically left or right.
5. Tool support, lifting arm and fixture are all driven by hydraulic pressure. The clamping force can be adjusted infinitely.
6. The standard configuration is hook with pressing wheel, and hook with pressing plate is optional .
7. The guide rail adopts the whole grinding process to ensure the precision of the guide rail and make the operation more stable.
