Product Details

Technical parameters

Rim diameter : 10"-30"

Max. wheel diameter: 1200mm

Tire width: 3"-16"

Working pressure: 0~13bar

Hydraulic motor: 1.5kw

Gear box motor:1.5kw

Voltage:415V/380V/220V/240V/110V

Machine weight: 188kg


Application range

Applicable for changing car tyres whose rim diameter is between 10"-30".

Suitable for RSC tyres. Suitable for mobile working.

Product features

Changing tyres of different rim diameters through adjusting changing head forward or back,when adjusted to the best position,it will be easy and smooth to change tyres and avoid hurting tyres.

Machine functions

1. Excellent electronic control system, automatically power off when the machine stops operating, safe, energy-saving, stable and efficient.

2. The center column integration 2.0, compared with the previous generation, changed from pneumatic to hydraulic. Compared with pneumatic, hydraulic is more stable, with better control and efficiency. The controllability continues the previous generation, and the overall performance is better than the previous generation.

3. The bottom bracket 2.0, compared with the previous generation, does not require follow-up maintenance and is not broken for life.

4. The central axis lock core system can be locked with a slight twist, the structure is simple and easy to operate, and the failure rate is extremely low.

5. The hydraulic system provides a strong power guarantee when working, and the stability brought by the combination with the electronic control system is unmatched by pneumatic products.

6. The large aluminum alloy cylinder with a diameter of 200mm, the tire is strong and powerful, and the working efficiency and service life are twice that of ordinary traditional machines.
